Description
Camera
Min. Illumination: | Color: 0.027 lux @(F2.0, AGC ON), 0 lux with IR
Shutter time: | 1/3 s to 1/100,000 s
Slow shutter: | Supported
Lens: | 80° (2.8 mm), 63.5° (4 mm), 50° (6 mm), 33° (8 mm)
Lens Mount: | M12
Adjustment Range: | Pan: 0° to 355°; Tilt: 0° to 75°; Rotate: 0° to 355°
Day& Night: | IR cut filter with auto switch
Wide Dynamic Range: | 120 dB
Digital noise reduction: | 3D DNR
Compression Standard
H.264 Type: | Main stream: H.265+ / H.265 / H.264+ / H.264; sub stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG; third stream:
H.265+ / H.265 / H.264+ / H.264
Triple Streams: | Yes
Max. Image Resolution: | 2048×1536
Main Stream: | 20 fps (2560 × 1920); 30 fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 x 720)
Third Stream: | 30 fps (1280 × 720, 640 × 360, 352 × 240)
Image Enhancement: | BLC/3D DNR
Image Settings: | Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
Day/Night Switch: | Auto/scheduled
Network
Network Storage: | Micro SD/SDHC/SDXC card with ANR (up to 128G), NAS (Support NFS, SMB/CIFS)
Alarm Trigger: | Motion detection, tampering alarm, network disconnect , IP address conflict, storage exception
Protocols: | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
System Compatibility: | ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI
Interface
Communication Interface: | 1 RJ45 10M / 100M Ethernet interface
On-board storage: | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Smart Feature-set
Behavior Analysis: | Line crossing detection, Intrusion detection, Region entrance, Region exiting, Unattended baggage, Object removal
Line Crossing Detection: | Cross a pre-defined virtual line
Intrusion Detection: | Enter and loiter in a pre-defined virtual region
Unattended Baggage: | Objects left over in the pre-defined region such as the baggage, purse, dangerous materials
Object Removal: | Objects removed from the pre-defined region, such as the exhibits on display.
Recognition: | Face detection recognition
General
Operating Conditions: | -30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing)
Power Supply: | 12 VDC ± 10%, PoE (802.3af)
Power Consumption: | 7 W
Impact Protection: | IK10
Weather Proof: | IP67
IR Range: | 30 meters
Dimensions: | Camera: 5.01″ x 3.78″ (Ø 127.3 x 95.9 mm); Package: 5.91″ x 5.91″ x 5.55″ (150 mm x 150 mm x 141 mm)
Weight: | 1.37 lbs (620 g)
