Description
Camera
Image Sensor: | 1/3″ Progressive Scan CMOS
Min. Illumination: | 0.01Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter time: | 1/3 s to 1/100,000 s
Lens: | 4mm, 6mm @ F2.0
Adjustment Range: | Pan: -30°-30°, Tilt: 0~75°, Rotation: 0-360°
Day& Night: | IR cut filter with auto switch
Wide Dynamic Range: | Digital WDR
Digital noise reduction: | 3D DNR
Compression Standard
Video Compression: | H.264/MJPEG/H.264+
Video bit rate: | 256Kbps~16Mbps
Audio Compression: | G.711/G.722.1/G.726/MP2L2
Max. Image Resolution: | 2560×1920
Frame Rate: | 50Hz:
20fps (2560×1920), 25fps (2048×1536), 25fps(1920×1080), 25fps(1280×720)
60Hz:
20fps (2560×1920), 30fps (2048×1536), 30fps(1920×1080), 30fps(1280×720)
Image Settings: | Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
BLC: | Yes, zone configurable
ROI: | Support
Network
Network Storage: | Micro SD/SDHC/SDXC card with ANR (up to 128G), NAS (Support NFS, SMB/CIFS)
Alarm Trigger: | Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception
Protocols: | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
System Compatibility: | ONVIF, PSIA, CGI, ISAPI
Interface
Communication Interface: | 1 RJ45 10M / 100M Ethernet interface
Alarm Input: | 1
Alarm Output: | 1
On-board storage: | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
General
Operating Conditions: | -30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing)
Power Supply: | 12 VDC ± 10%, PoE (802.3af)
Power Consumption: | 5W MAX
Impact Protection: | IK08 Protection Level
Weather Proof: | IP67
IR Range: | 10 meters
Dimensions: | 99.3×96.7×52.8(mm)
Weight: | 600 g (1.32 lbs)
