Description

Camera

Image Sensor: | 1/3″ Progressive Scan CMOS
Min. Illumination: | Color: 0.028 @ ƒ/2.0, AGC on), BW: 0 lux with IR
Shutter time: | 1/3 s to 1/10,000 s
Slow shutter: | Supported
Lens: | 4 mm, 6 mm options; angle of view: 83° (4 mm), 56° (6 mm)
Lens Mount: | M12
Day& Night: | IR cut filter with auto switch
Wide Dynamic Range: | 120 dB
Digital noise reduction: | 3D DNR
Compression Standard
Video Compression: | H.264/MJPEG/H.264+
H.264 Type: | Main profile
Video bit rate: | 256 Kbps – 16 Mbps
Dual Stream: | Yes


Max. Image Resolution: | 2688×1520
Frame Rate: | 20 fps (2688 × 1520), 30 fps (1920 × 1080), (1280 × 720)
Image Settings: | Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
BLC: | Yes, zone configurable
ROI: | Yes
3D DNR: | Supported

Network

Network Storage: | NAS (Support NFS,SMB/CIFS)
Alarm Trigger: | Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception
Protocols: | TCP/IP, ICMP,H TTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Security: | Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access
System Compatibility: | ONVIF, PSIA, CGI, ISAPI
Interface
Communication Interface: | 1 RJ45 10M / 100M Ethernet interface

General

Operating Conditions: | -30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing)
Power Supply: | 12 VDC ± 10%, PoE (802.3af)
Power Consumption: | Max. 7.5W
Weather Proof: | IP67
IR Range: | 50 meters
Dimensions: | 299.71 mm × 86.48 mm × 85.11 mm (11.8″ × 3.4″ × 3.35″)
Weight: | 1200 g (2.65 lbs)
