Description

Camera

Image Sensor: | 1/3″ (5 MP) Progressive Scan CMOS
Effective Pixels: | 2592 (H) × 1944 (V)
Min. Illumination: | Color: 0.01 lux @ (F1.2,AGC ON), 0 lux with IR
Shutter Time: | PAL: 1/25 s to 1/50,000 s NTSC: 1/30 s to 1/50,000 s
Lens: | 2.8 mm, 3.6 mm, 6 mm, 8 mm, 12 mm fixed focal lens
Lens Mount: | M12
Day & Night: | ICR
Synchronization: | Internal
Video Frame Rate: | 2592 × 1944 @ 20 fps
HD Video Output: | 1 HD-TVI analog output

Menu

AGC: | Supported
D/N Mode: | Auto / color / BW (black and white)
White Balance: | ATW / MWB
BLC: | Supported
Language: | English, Chinese
Functions: | Brightness, sharpness, digital noise reduction, mirror, bad pixel correction, smart IR

General

Working Temperature/Humidity: | -40° F to 140° F (-40° C to 60° C), Humidity 90% or less (non-condensing)
Power Supply: | 12 VDC ± 30%
Power Consumption: | Maximum 5 W
IR Range: | Up to 120 ft (40 m)
Communication: | Up-the-Coax Protocol: HIKVISION-C (HD-TVI output)
Dimensions: | Φ 4.33″ × 3.67″ (Φ 110 mm × 93.2 mm)
Weight: | 0.77 lbs (approximately 350g )
