Description

Camera Module

Image Sensor: | 1/1.9″ progressive scan CMOS
Min. Illumination: | ƒ/1.5, 50 IRE, AGC on; color: 0.02 lux, B/W: 0.002 lux, 0 lux with IR
Max. Image Resolution: | 4096 x 2160
Focal Length: | 5.7 mm to 205.2 mm, 36x
Digital Zoom: | 16x
Zoom Speed: | Approximately 7.4 s (optical wide-tele)
Angle of View: | 56.8° to 2.02° (wide-tele)
Min. Working Distance: | 10 mm to 1500 mm (wide-tele)
Aperture Range: | ƒ/1.55 to ƒ/4.8
Focus Mode: | Auto/semiautomatic/manual
WDR: | 120 dB
Shutter Time: | 50 Hz: 1 to 1/30,000 s; 60 Hz: 1 to 1/30,000 s
AGC: | Auto/manual
White Balance: | Auto/manual/ATW/indoor/outdoor/daylight lamp/sodium lamp
Day & Night: | IR cut filter
Privacy Mask: | 24 privacy masks programmable
Enhancement: | 3D DNR, HLC/BLC, SVC
Defog: | Supported

PTZ

Range: | Pan: 360° endless; tilt: -20° to 90° (auto flip)
Speed: | Pan manual speed: 0.1° to 160°/s, pan preset speed: 240°/s
Tilt manual speed: 0.1° to 120°/s, tilt preset speed: 200°/s
Number of Preset: | 300
Patrol: | 8 patrols, up to 32 presets per patrol
Pattern: | 4, with recording time not less than 10 minutes per pattern
Park Action: | Preset, patrol, pattern, auto scan, tilt scan, random scan,
frame scan, panorama scan
Scheduled Task: | Preset, patrol, pattern, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output

Smart Features

Smart Tracking: | Manual, panorama, intrusion trigger, line crossing trigger,
region entrance trigger, region exiting trigger, smart tracking when patrol between multiple scenarios
Smart Detection: | Intrusion detection, line crossing detection, audio exception detection, region entrance detection, region exiting detection
ROI encoding: | Supports 6 areas with adjustable levels

Alarm

Alarm I/O: | 7/2
Alarm Trigger: | Intrusion detection, line crossing detection,
region entrance, region exiting, audio exception detection,
motion detection, dynamic analysis, tampering alarm, network
disconnect, IP address conflict, storage exception
Alarm Action: | Preset, patrol, pattern, microSD/SDHC card recording, relay output, notification on client, send e-mail, upload to FTP, trigger channel

Input/Output

Monitor Output: | 1.0 V[p-p]/75 Ω, NTSC (or PAL) composite, BNC (S/N
Ratio ≥ 55 dB)
Audio Input: | 1 mic in/line in interface, line input: 2-2.4 V[p-p]; output impedance: 1K Ω, ±10%
Audio Output: | 1 audio output interface, line level, impedance: 600 Ω

Network

Ethernet: | 10Base-T/100Base-TX, RJ-45 connector
Image Compression: | H.264/MJPEG, H.264 encoding with
Baseline/Main/High profile
Audio Compression: | G.711ulaw/G.711alaw/G.726/MP2L2/G.722/PCM
Protocols: | UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP,
UDP, IGMP, ICMP, DHCP, PPPoE
Simultaneous Live View: | Up to 20 simultaneous users
Mini SD Memory Card: | Supports up to 128 GB microSD/SDH C/SDXC card
Supports Edge recording
User/Host Level: | Up to 32 users, 3 levels: administrator, operator, and user
Security Measures: | User authentication (ID and PW), host authentication
(MAC address), IP address filtering
Main Stream: | 50 Hz: 25 fps (4096 × 2160, 3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720);
60 Hz: 24 fps (4096 × 2160), 30 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
Sub Stream: | 50 Hz: 25 fps (704 × 576, 352 × 288, 176 × 144);
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
Third Stream: | 50 Hz: 25 fps (704 × 576, 352 × 288, 176 × 144);
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)

System Integration

Application programming: | Open-ended API, supports ONVIF, PSIA, CGI, and Genetec
Web Browser: | IE 7+, Chrome 18+, Firefox 5.0+, Safari 5.02+,
supports multi-language
RS-485 Protocols: | HIKVISION, Pelco-P, Pelco-D, self-adaptive
Certification: | FCC, CE, UL, RoHS, IEC/EN 61000, IEC/EN 55022,
IEC/EN 55024, IEC/EN60950-1

IR

IR Distance: | Up to 1,640 ft (500 m)
IR Control: | Automatically adjusted, depending on the zoom ratio
General
Protection Level: | IP66, IK10, TVS 6,000 V lightning protection, surge
protection and voltage transient protection
Working Environment: | -40° F to 149° F (-40° C to 65° C), humidity: 90% or less
Power: | High-PoE and 24 VAC, maximum 60 W
Dimensions: | ϕ 10.5″ x 17.13″ (ϕ266.6 mm × 435 mm)
Weight: | 17.64 lbs (8 kg)
