Description
GENERAL SPECIFICATIONS
- WEIGHT OF THE FOG MACHINE About 9 kg
- WEIGHT WITH PACKAGING About 11 kg
- UNITS ON ONE PALLET 100X120 30
- DIMENSION OF THE MACHINE 26,5×23,0xh34,5
- DIMENSION OF THE PACKAGING 32,0×25,0xh43,0
COLORS White/Black
- WORKING TIME WITHOUT MAINS POWER About 2 hours
- HEAT UP TIME FROM COLD about 70 minutes
- VERTICAL OR CORNER MOUNTING yes
- HORIZONTAL MOUNTING no
- SERIAL/USB PORT FOR MONITORING yes
- NOZZLE TAMPER no
- SERIAL BUS FOR STANDARD PROTOCOL yes
- ALARM KIT optional
FOG GENERATOR
- NEW HEATING SYSTEM PLUS yes
- MAX FOG SINGLE SHOT 1,5 M VISIBILITY up to 250 m3
- MAX FOG SINGLE SHOT ZERO VISIBILITY up to 210 m3
- MAX SECONDS OF FOG 25 sec
- MAX FOG EMISSION WITH FULL FOG TANK 250 m3
- NUMBER OF FLUID TANK 1
- FLUID TANK CAPACITY 165 ml
- SHOOTING SPECIFICATION single shot
- CYLINDER MODEL 03 E200
- CYLINDER INCLUDED NO
- DOUBLE FOG TANK ADVANTAGE NO
ELECTRICAL SPECIFICATIONS
- POWER SUPPLY 220 OR 110V
- AVERAGE POWER CONSUMPTION 37W
- BACK UP BATTERY YES
- OPTIONAL DEMO/ANTIROBBERY KIT YES
- WIRED INPUTS ARMING AND SHOOTING YES
- WIRED OUTPUTS YES
- STANDARD COMMUNICATION PROTOCOL YES
- STANDARDS
- COMPLIES WITH EUROPEAN CE YES
- FOG FLUID IS CERTIFIED YES
- MEETS EUROPEAN STANDARD YES
